ISO C11
Checked admission, trusted Ordered execution, terminal-depth profiles, canonicalization, compute libraries, CLIs, examples, and exhaustive tests.
K — Dendritic Structural Encoding (KDSE)
UHWare · C11 and Python reference implementations of KDSE-8 and KDSE-16
Public reference implementations · v1.0.3Introduction
K — Dendritic Structural Encoding (KDSE) is UHWare's compact, delimiterless breadth-first encoding of finite full dendrites that supports both binary and q-ary forms. It defines Ordered canonical forms, terminal-depth profiles, and a deterministic threshold-and-loss operator.
The mathematical specification is language-independent. This release provides portable C11 and Python reference implementations of the KDSE-8 and KDSE-16 container forms.
Read the technical specification for the structural definition, validity rules, container distinction, and operator boundary.
New in v1.0.3: Python reference implementation
Full KDSE-8 and KDSE-16 APIs, command-line tools, exhaustive tests, direct C-reference parity checks, and a bidirectional Mermaid structural adapter. View the release.
Core definition
- Tree class
- Structural KDSE uses finite full (proper) binary trees: each node has either zero or two children.
- Bit semantics
1denotes a branch that creates two children;0denotes a terminal leaf.- Emission order
- Bits are emitted breadth-first, with the upper child before the lower child.
- Compactness
- Only positions generated by preceding branch bits are encoded; the final all-terminal level is implicit and omitted.
- Values
- Values are independent of the structure and are listed in the same breadth-first order, including final leaves.
- Ordered form
- Ordered KDSE is a canonical subtype; a valid structural KDSE may use any full binary topology, including an unbalanced one.
Reference Implementations
Python 3.10+
C-aligned validation, profiles, Ordered canonicalization,
computation, status codes, kdse-py and
kdse16-py, plus KDSE ↔ Mermaid conversion.
The v1.0.3 validation suite passes all C tests and all 37 Python tests, including direct parity against the C reference.
Papers
1. Introductory Paper
Structural definition, Ordered form, and operator separation.
Read HTML ·
Download PDF
2. Instantaneous Jump Magnitude Paper
Threshold-and-loss operator and the identity Jd = T · cd.
Read HTML ·
Download PDF
Source Code
Complete v1.0.3 source archives:
Live repository: github.com/uhware/kdse
